CAMERA |
Detector Type | Long-Life,Uncooled IRFPA Microbolometer |
Effective Resolution | 396x264 |
Pixel Pitch | 20μm |
Sensitivity | 50mK |
Spectral Range | 8 to 14μm |
Temperature Detection | Yes |
Vision Lens | 3.3~10.5mm, 7~22mm, AUTO IRIS(Optional) |
Thermal Lens | F1.0, 15mm,25mm,50mm , |
Motorized 25mm,50mm |
Focus | Manual/Motorized |
FOV(Fixed Lens) | 24°×18°/14.6°×11°/7.3°×5.5° |
Temperature Detect Distance(Fire) | 300m(Lens:15mm) / 500m(Lens:25mm) / 1500m(Lens:50mm) |
Fixed Lens Recognition Distance (Body) | 200/300/650m |
Fixed Lens Recognition Distance(Vehicle) | 350/600/1200m |
IR Range | 30~80m |
IMAGE |
Video Compression | H.264 High/Main/Baseline Profile, MJPEG |
Bit Rate (CBR/VBR) | 500kb~10Mb |
Audio Compression | G.711 ,RAW_PCM |
Thermal Resolution | D1/30fps |
Vision Resolution | 1080P/30fps |
Stream | D1 ,CIF |
Image Color Mode | Black-Heat /White-Heat/Rainbow/Iron-Red up to 17 modes |
DVE Image Enhance | Yes |
3D Noise Reduce | Yes |
Image Correction | Auto/Manual/External |
Image Overturn | Horizontal /Vertical /Horizontal+Vertical |
NETWORK |
Network Protocols | IPv4/v6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPOE,SMTP,SIP |
Alarm Trigger | Temperature Alarm,Motion Detection,Network disconnect,Disk alarm,I/O alarm |
RTSP Video | Standard RFC2326, Support QuickTime / VLC Player. |
Security | User security authentication, Reset, Hardware WatchDog |
Web Language | English, Chinese |
System Compatibility | Onvif |
INTERFACE |
Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
Audio I/O | Optional |
Alarm I/O | Optional |
RS485 | Yes |
BNC Output | Yes |
Reset Button | Yes(built-in) |
Edge Storage | Micro SD/SDHC slot ,Max 32GB |
GENERAL |
Power Supply | DC12V |
Power Consumption | 10W(MAX) |
OperatingTemperature | -25 °C ~ 55 °C (-13 °F ~ 131 °F) |
Ingress Protection | IP66 |
Approvals | CE / FCC |
Product Dimensions | 463×188×120mm |
Product Weight | 5kg |
