| CAMERA |
| Detector Type | Long-Life,Uncooled IRFPA Microbolometer |
| Effective Resolution | 396x264 |
| Pixel Pitch | 20μm |
| Sensitivity | 50mK |
| Spectral Range | 8 to 14μm |
| Temperature Detection | Yes |
| Vision Lens | 40X Optical Zoom, 7.75mm(F1.6)~310mm(F5.6) |
| Thermal Lens | Motorized 75mm ,100mm optional |
| Focus | Motorized |
| FOV | 4.8°×3.6°/3.6°×2.7° |
| Temperature Detect Distance(Fire) | 2000m （Lens:75mm）,2600m（Lens:100mm） |
| Motorized Lens Recognition Distance (Body) | 800m/1000m |
| Motorized Lens Recognition Distance (Vehicle) | 1500m/2000m |
| IMAGE |
| Video Compression | H.264 High/Main/Baseline Profile, MJPEG |
| Bit Rate (CBR/VBR) | 500kb~10Mb |
| Audio Compression | G.711 ,RAW_PCM |
| Thermal Resolution | D1/30fps |
| Vision Resolution | 1080P/30fps |
| Stream | D1 ,CIF |
| Image Color Mode | Black-Heat /White-Heat/Rainbow/Iron-Red up to 17 modes |
| DVE Image Enhance | Yes |
| 3D Noise Reduce | Yes |
| Image Correction | Auto/Manual/External |
| Image Overturn | Horizontal /Vertical /Horizontal+Vertical |
| NETWORK |
| Network Protocols | IPv4/v6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPOE,SMTP,SIP |
| Alarm Trigger | Temperature Alarm,Motion Detection,Network disconnect,Disk alarm,I/O alarm |
| RTSP Video | Standard RFC2326, Support QuickTime / VLC Player. |
| Security | User security authentication, Reset, Hardware WatchDog |
| Web Language | English, Chinese |
| System Compatibility | Onvif |
| INTERFACE |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio I/O | Optional |
| Alarm I/O | Optional |
| RS485 | Yes |
| BNC Output | Yes |
| Reset Button | Yes(built-in) |
| Edge Storage | Micro SD/SDHC slot ,Max 32GB |
| GENERAL |
| Power Supply | AC24V ±10% |
| Power Consumption | 40W(MAX) |
| OperatingTemperature | -25 °C ~ 55 °C (-13 °F ~ 131 °F) |
| Ingress Protection | IP66 |
| Approvals | CE / FCC |
| Product Dimensions | 463x310x303.6mm |
| Product Weight | 22kg |
