Standard Compliance | IEEE 802.3u 100BASE-TX Ethernet* |
IEEE 802.3ab 1000BASE-T Ethernet* |
IEEE 802.3z 1000BASE-X* |
IEEE 802.3af PoE* |
IEEE 802.3at PoE Plus* |
IEEE 802.3az EEE* |
IEEE 802.3x flow control |
IEEE 802.1AB LLDP/LLDP-MED |
IEEE 802.3ad LACP aggregation* |
IEEE 802.1D Spanning Tree Protocol (STP)* |
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)* |
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) |
IEEE 802.1Q VLAN tagging |
IEEE 802.1p Class of Service (CoS) prioritization* |
IEEE 802.1X port authentication* |
Resilience and Availability | IEEE 802.1D Spanning Tree Protocol (STP)* |
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)* |
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) |
IEEE 802.3ad LACP (Max # Trunks/Links per Trunk): 8/8* |
Loop guard* |
ErrDisable recovery |
MRSTP (Zyxel proprietary) |
Dual configuration files |
Dual images* |
Traffic Control | 802.1Q Static VLANs*/Dynamic VLANs: 1K/4K |
Port-based VLAN* |
Protocol-based VLAN |
VIP Subnet-based VLAN |
MAC-based VLAN |
Private VLAN |
Voice VLAN* |
VLAN ingress filtering |
LACP algorithm of source/destination MAC/IP |
GVRP |
L2PT |
Security | 802.1X* |
Port security* |
Layer 2 MAC filtering |
Layer 3 IP filtering |
Layer 4 TCP/UDP socket filtering |
Static MAC forwarding |
Multiple RADIUS servers* |
Multiple TACACS+ servers |
802.1x VLAN and 802.1p assignment by RADIUS |
Login authentication by RADIUS* |
Login authentication by TACACS+ |
TACACS+ accounting |
Authorization on RADIUS* |
Authorization on TACACS+ |
SSL* |
MAC freeze |
DHCP snooping IPv4* |
DHCP snooping IPv6 |
ARP inspection |
Static IP-MAC-Port binding |
Policy-based security filtering |
Port isolation |
IP source guard |
MAC search |
Guest VLAN* |
ACL packet filtering (IPv4/IPv6)* |
CPU protection |
Interface related trap enable/disable (by port) |
IPv6 duplicated address detection (DAD) |
Quality of Service (QoS) | No. of hardware queues per port: 8* |
802.1p queuing methods: SPQ, WRR, WFQ* |
Storm control: broadcast, multicast, unknown unicast (DLF)* |
Port-based rate limiting(ingress/egress) |
Rate limiting per IP/TCP/UDP per port |
Policy-based rate limiting |
802.3x flow control |
802.1p Class of Service (SPQ, WFQ, SPQ/WFQ combination capable) |
DiffServ (DSCP) |
Layer 2 Multicast | L2 multicast |
IGMP snooping (v1, v2, v3)* |
IGMP snooping fast Leave |
Configurable IGMP snooping timer and priority |
IGMP snooping statistics |
IGMP throttling |
MVR support |
IGMP filtering |
IGMP snooping immediate leave |
IGMP proxy mode & snooping mode selection* |
MLD snooping |
Manageability | SNMP v1, v2c, v3 |
SNMP trap group |
RMON (1, 2, 3, 9) |
ICMP echo/echo reply |
Syslog* |
IEEE 802.1AB LLDP |
IEEE 802.1AB LLDP-MED |
Custom default |
Syslog (IPv4/IPv6) |
Display port utilization* |
Support NebulaFlexTMfor hybrid mode |
IPv6 Management | IPv6 over Ethernet (RFC 2464) |
IPv6 addressing architecture (RFC 4291) |
Dual stack (RFC 4213) |
ICMPv6 (RFC 4443) |
Path MTU (RFC 1981) |
Minimum path MTU size of 1280 (RFC 5095) |
Encapsulation for maximum MTU of 1500 |
Neighbor discovery (RFC 4861) |
DHCPv6 relay |
Default DHCP client mode* |
DAD (Duplicated Address detection) |
Device Management | Standalone management by Web interface |
Cloud management by Nebula Control Center* |
Zyxel iStackingTM |
Web interface |
Management through SNMP |
Remote firmware upgrade by Web |
Configuration saving and retrieving |
Configure clone |
DHCP relay per VLAN |
DHCP client IPv4* |
DHCP client IPv6 |
Daylight saving* |
NTP Server (IPv4/IPv6) – Support DNS format* |
Port mirroring* |
Scheduled PoE* |
PoE default consumption mode* |
Restore to last custom default |
* Cloud management mode supports features. |
MIB | Zyxel private common MIB |
RFC 1066 TCP/IP-based MIB |
RFC 1213, 1157 SNMPv2c/v3 MIB |
RFC 1493 bridge MIB |
RFC 1643 Ethernet MIB |
RFC 1757 RMON Group 1, 2, 3, 9 |
RFC 2011, 2012, 2013 SNMPv2 MIB |
RFC 2233 SMIv2 MIB |
RFC 2358 Ethernet-like MIB |
RFC 2674 bridge MIB extension |
RFC 2819, 2925 remote management MIB |
RFC 3621 power Ethernet MIB |
RFC 4022 management information base for transmission control protocol |
RFC 4113 management information base for user datagram protocol |
| RFC 4292 IP forwarding table MIB |
| RFC 4293 Management Information Base (MIB) for IP |
Certifications | Safety |
LVD |
BSMI |
EMC |
FCC Part 15 (Class A) |
CE EMC (Class A) |
BSMI ENC |
RoHS |
Level A |
Zyxel One Network | ZON Utility |
Discovery of Zyxel switches, APs and gateways |
Centralized and batch configurations: |
IP configuration |
IP renew |
Device factory reset |
Device reboot |
Device locating |
Web GUI access |
Password configuration |
One-click quick association with Zyxel AP Configurator (ZAC) |
Automatic detection of the latest firmware |
Displays device serial number and hardware version |
Cloud mode on/off option for Hybrid series devices |
Smart Connect |
Discover neighboring devices |
One-click remote management access to the neighboring Zyxel devices |
Reset neighboring devices remotely to factory defaults |
Power cycle neighboring powered devices (PoE switches only) |
Limited life-time warranty | Warranty terms, service availability, and service response times may vary from country or region to country or region. |
* Cloud management mode supports features. |
